80 plus certification: 80 PLUS Platinum
ac input frequency: 50/60 Hz
ac input voltage: 100 - 240 V
amd opteron series: 9000
built-in processor: No
certification: BSMI, CE, CB, C-Tick, FCC(Class A)
chassis type: Rack (1U)
compatible processor series: AMD EPYC 9004
cooling type: Active
depth: 842.5 mm
ethernet interface type: 10 Gigabit Ethernet
ethernet lan: Yes
ethernet lan (rj-45) ports: 3
ethernet lan data rates: 10000 Mbit/s
height: 43.9 mm
hot-swap hdd bays: Yes
integrated bmc with ipmi: Yes
ipmi lan (rj-45) port: Yes
lan controller: Intel® I350-AM4
led indicators: Yes
maximum rdimm memory: 3.07 TB
number of dimm slots: 24
number of m.2 (m) slots: 2
number of redundant power supplies supported: 2
number of storage drives supported: 14
on-board graphics card memory: 64 MB
on-board graphics card model: Aspeed AST2600
operating relative humidity (h-h): 20 - 90%
operating temperature (t-t): 10 - 35 °C
package weight: 19.9 kg
pci express slots version: 4.0
pci express x16 slots: 1
pci express x4 slots: 1
pci express x8 slots: 1
power supply: 2600 W
processor family: AMD
processor manufacturer: AMD
processor socket: Socket SP5
product colour: Steel
redundant power supply (rps) support: Yes
storage drive sizes supported: 2.5
storage relative humidity (h-h): 20 - 90%
storage temperature (t-t): -40 - 60 °C
supported dimm module capacities: 64GB
supported memory types: DDR5-SDRAM
supported storage drive interfaces: Serial ATA, Serial Attached SCSI (SAS)
supported storage drive types: HDD & SSD
trusted platform module (tpm): Yes
trusted platform module (tpm) version: 2.0
usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: 2
vga (d-sub) ports quantity: 1
weight: 14.9 kg
width: 449 mm
